What Is a Cargo Elevator Platform?
A cargo elevator platform (freight lift) is a compact hydraulic lifting system designed to transport goods, pallets, and materials between floors of commercial, industrial, and residential buildings. Unlike passenger elevators, freight lifts prioritize load capacity, open platform access, and ease of forklift or pallet-truck loading. They are the efficient, low-cost alternative to full elevator shafts for goods movement.
Key Advantages
Freight Lift
model: LGH0.5 Series
Model variants
| Model | Capacity | Platform | Lift height | Motor |
|---|---|---|---|---|
| LGH0.5-3 | 500 kg | 1000×1000 mm | 3000 mm | 2.2 kW |
| LGH0.5-5 | 500 kg | 1000×1000 mm | 6000 mm | 2.2 kW |
| LGH0.5-7 | 500 kg | 1000×1000 mm | 8000 mm | 3 kW |
| LGH0.5-9 | 500 kg | 1000×1000 mm | 10000 mm | 3 kW |
Freight Lift
model: LGH1 Series
Model variants
| Model | Capacity | Platform | Lift height | Motor |
|---|---|---|---|---|
| LGH1-3 | 1000 kg | 1200×1500 mm | 3000 mm | 3 kW |
| LGH1-4 | 1000 kg | 1200×1500 mm | 4000 mm | 3 kW |
| LGH1-6 | 1000 kg | 1200×1500 mm | 6000 mm | 3 kW |
| LGH1-8 | 1000 kg | 1200×1500 mm | 8000 mm | 3 kW |
| LGH1-10 | 1000 kg | 1200×1500 mm | 10000 mm | 3 kW |
Why Choose DAKAlift Freight Lifts?
Safe by Design
24V DC safety circuit, explosive-proof valve, landing limits, and interlocked railings, all standard, no extras.
Minimal Pit Depth
200–250 mm minimum pit means most existing floor slabs can accommodate installation with minimal civil work.
3-Side Access
Load and unload from three sides. Flexible orientation adapts to any building layout or loading direction.
5-Year Warranty
Structural components are warranted for 5 years for indoor use. 1 year on all electrical components.
Multi-Voltage Supply
Compatible with 220V, 240V, 380V, and 415V supplies — works in any country, any facility type.
Full Customization
Platform size, capacity, travel height, and enclosure type are all project-configurable. Nothing is off-the-shelf.
